HP_54615B oscilloscope

HP 54615B 500 MHz 1 Gsa/sec Digital Storage Oscilloscope with HP54657A Storage / HP-IB Module

The HP 54615B is a 500 MHz, 1 GSa/s digital oscilloscope with 1ns peak detect. It has a resolution of 8 bits, and record length is 5000 points. With the HP 54657A module, the scope can calculate an FFT spectrum and subract, multiply, integerate and differentiate signals. This module also provides a GPIB/HP-IB control interface.

About this scope

This used HP 54615B oscilloscope is in excellent condition. It includes the 54657A measurement/storage and HP-IB module. It has been calibrated, fully tested and all functions are working. The self test passes, and the floppy drive works properly. Both input channels and the external trigger inputs have also been tested and work properly.

More details are available in the following documents:

Included Items

  • HP 54615B Oscilloscope
  • HP 54657A Measurement/Storage/GPIB Module (installed on scope)
  • CD containing User/Service Manual and Data Sheet
  • Power Cord
  • 2 new 100 MHz Probe kits including probes, clips, and colored rings

Specifications

Bandwidth (-3dB): DC to 500 MHz x 2 channels
Single-shot Bandwidth (-3dB): DC to 250 MHz
Number of Channels: 2
Sensitivity: 2mV/div to 5V/div
Max Input: 250V, or 5Vrms in 50-ohm mode
Timebase: 5 s/div to 1 ns/div
Trigger Sources: Ch1,Ch2,Ext,Line
Horizontal resolution: 100 ps
Max Sample Rate: 1 GSa/s
Resolution: 8 bits
Max Display Update Rate: 500,000 points/sec
Size: 6.8 x 12.7 x 12.5 in
Weight: 14 pounds
Power Requirements: 100-240 VAC, 45 to 440 Hz
